Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine

Get high-quality macrame lace fabrics with our advanced automatic dyeing machine. We are a factory with a commitment to superior dyeing and quality control.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
HR
Voltage
380V/50Hz 3phase Can Be Customized
Load Capacity
1000-2000kg
Certification
CE, ISO9001: 2000
Warranty
1 Year
Customized
Customized
Condition
New
Machine Item
Automatic Control Lace Fabric Jet Sample Dyeing Ma
Machine Painting Color
Be Made According to Your Need
Price
Lowest Reasonable Offers in The Market
After-Sales Service
24 Hours Technical Support by Email, Call, Video
Warranty Time
Offer Free Spare Parts and Service Within 12 Month
Working Experience
32 Years′ Experience
Delivery Date
Fast Delivery in 30 Days
Power(W)
45kw
Length of Tube
1200-2000mm
Steam Working Pressure
0.3MPa
Heating
Direct Steam/Indirect Steam
Dimension(L*W*H)
13860*2980*2650
Length of Hank
820mm
Max.Working Temperature
98 Degree
Transport Package
Standard Package or Nude Package Customized
Specification
Dimension(L*W*H): 13860*2980*2650
Trademark
HUARUI
Origin
Qingdao City
HS Code
8451290000
Production Capacity
100/Week

Product Description

Brief introduction:

PRODUCT CHARACTERISTICS
1. The machine is basically composed of cloth storage tank, circulation system, filter and heat exchanger, feed drum [sub-cylinder] cloth outlet roller, fold and folding device and control system.
2. The circulation of the dyeing liquid is realized by the circulation pump directly driven by the motor. The circulation pump sucks the dye liquor at the bottom of the machine and sends it to the nozzle through the heat exchanger. The nozzle pressure is adjusted by the throttle valve installed on the outlet of the circulation pump. When the main pump motor is driven by the inverter, there is no throttle valve .
3. The pressure gauge and the temperature gauge are installed on the machine, which are used to display the nozzle pressure and the dye liquor temperature, respectively.
4. The front part of the heat exchanger is a filter, which is equipped with a filter screen for blocking the debris in the circulating liquid flow. The heat exchanger is equipped with a heating/cooling valve for heating/cooling the dye liquor.
5. The rope-like fabric runs to the front in the cloth storage tank, which is lifted by the lifting drum driven by the frequency conversion speed regulation motor, and its speed is displayed on the speed display on the electric control box.
6. Feeding tank [sub-cylinder] is used for the preparation of dyes and chemical agents. Open the water inlet valve or the return valve to put the clean water or dye liquor into the feeding tank. The stirring of the solution in the tank can be performed by an electric agitator, which will directly steam The heating valve opens to heat the liquid.
7. Warning: When the temperature of the dye liquor exceeds 85°C [185°F], it is not allowed to open the return valve.



Detail machine pictures, all photoes are for 100% real shooting ! For more pictures, video and details, please email me!
Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine
Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine

1. The rope-like fabric runs to the front in the cloth storage tank, which is lifted by the lifting drum driven by the frequency
conversion speed regulation motor, and its speed is displayed on the speed display on the electric control box.

2. Feeding tank [sub-cylinder] is used for the preparation of dyes and chemical agents. Open the water inlet valve or the return valve to put the clean water or dye liquor into the feeding tank. The stirring of the solution in the tank can be performed by an electric agitator, which will directly steam The heating valve opens to heat the liquid.
3. Warning: When the temperature of the dye liquor exceeds 85°C [185°F], it is not allowed to open the return valve.

Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine

OUR ADVANTAGES
1) Excellent, high corrosion-resistant stainless steel
2) Ultra-low bath ratio , Wisdom, energy saving and environmental protection
3) Humanized design Automatic lifting bracket
4) Automatic feeding system Precision feeding
5) Direct heating and indirect heating combined
6) Won the invention and utility model patent certificate


Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine

Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine
Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine

Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine

Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine


Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine
Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine
Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine
Macrame Automatic Control Lace Fabric Jet Sample Dyeing Machine
